CCT Europe is a distributor of high tech products for the European industry.
We address the following markets:

Semiconductor Industry
We are focussing on the Wet Process Areas with our Dainichi Wafer Hadling products like Carriers, Boxes, FOUP and RSP, Altaflo UHP PFA, FEP, PVDF Tubing, Fit-Line, IPS & Flowell fittings, IPS & Megaflow Valves, Spray Guns and other accessories.
Because we represent companies like IPS and Megaflow, we can also help in cost reduction with tool maintenace.
We can offer Original Machine Parts supplied by IPS for several AMAT (Reflexion LK CMP, Desica Vapor Dryer System) Semitool and FSI equipment.
If you work with the AMAT Mirra Tool we can offer Second Source valves as replacement of the Saint-Gobain/Furon 2 and 3 way valve. (UPM3-644)

Due to the use of isolators like teflon in these areas also ESD can be a significant problem/issue which need to be addressed.
CCT Europe has the knowledge and experience due to our long term relationship with Simco-Ion for which we work as a distributor addressing their Electronics products mainly used within cleanroom applications.
We can help checking areas to see if static charge is present, and we then can offer possible solutions with our braod range of ionisation equipment.

If your company is doing Wafer Thinning, and wants reliable Thickness, Bow, Warp, TTV Measurements, then the Proforma series from MTI Instruments is the right tool to consider.
MTI Instruments' semiconductor wafer metrology tools consist of a complete line of wafer measurement systems for virtually any material including Silicon wafer (Si), Gallium Arsenide wafer (GaAs), Germanium wafer (Ge) and Indium Phosphide wafer (InP). From manual to semi-automated wafer inspection systems, the Proforma line of wafer metrology inspection tools is ideal for wafer thickness, wafer bow, wafer warp, resistivity, site and global flatness measurement. Our proprietary push/pull capacitance probes provide outstanding accuracy throughout their large measurement range, allowing measurement of highly warped wafers and stacked wafers.

Solar Industry
Like for the Semiconductor Thickness Measurement, MTI Instruments has the PV-1000, which is based upon the same Technology.
High-speed, multi-channel thickness, Total Thickness Variation (TTV) and wafer bow measurement module for in-process monitoring of solar / photovoltaic wafers and other materials. For applications requiring additional thickness channels or for unlimited line scans on solar / photovoltaic wafers, multiple PV-1000 measurement tools can be chained together.

For the panel manufacturers in Italy and estern Europe CCT can offer high quanlity Ribbon Wire from TSW (Torpedo Specialty Wire), and backsheet materials from CPP Solar.

Precision Measurement Applications
Besides the Semiconductor, solar and other High Tech industries, we can help you with specific measurenment issues.
MTI Instruments also offers non-contact Laser, Fiber-optic and Capacitance measurement systems for a wide variety of displacement, position, vibration and dimensional gaging applications.
Check out MTI's selection of non-contact tensile, compression and bending fixtures, precision signal source / function generators, eddy current and inductive systems and amplifier calibration fixtures.


We are proud to offer quality products for these industries and thus be able to contribute to the European challenge in becoming front runners in their disciplines.


We will constantly try to listen to your needs and to find suitable solutions for your technical problems
